TP-Link TL-PoE170S Non-PoE to PoE Adapter

MODEL: POE170S-Black

Convert Non-PoE to PoE: With no need to replace your existing non-PoE switch/device, you can easily have PoE enabled with the use of TL-PoE170S. High Speed Gigabit Ports: experience lightning-fast wired speeds with 1_ Gigabit Ethernet Input Port + 1_ Gigabit Ethernet Output port. 802.3at/af/bt PoE Compliant: TL-PoE170S supplies power and data via one single ethernet cable to 802.3 at/af/bt PoE devices and expands network to areas with no power lines or outlets. Plug and Play Installation: Easy setup with no software installation or configuration needed. Long Range Transmission: Deliver Power up to 100 meters (328ft.), perfect for IP cameras or access point deployment in large areas.

| |

FULL SPECIFICATION

Network Media:
* 10BASE-T: UTP category 3, 4, 5 cable (maximum 100 m)
* EIA/TIA-568 100Ω STP (maximum 100 m)
* 100BASE-TX: UTP category 5, 5e cable (maximum 100 m)
* EIA/TIA-568 100Ω STP (maximum 100 m)
* 1000BASE-T: UTP category 5, 5e, 6 cable(maximum 100 m)
Ports:
* 1 10/100/1000Mbps RJ45 data-in port
* 1 10/100/1000Mbps RJ45 power+data-out port
* 1 AC socket
Power Consumption:
* Input: 100-240 V, 50/60 Hz, 1.6A
* Output: Auto-determine the necessary power requirements (max. 60 W)
Basic Function:
*Auto-Sensing Algorithm enables providing power with 802.3af/at/bt* PD
* Auto-determine the necessary power requirements
* Wall-mounting and desktop installation supported
* Plug-and-Play
Dimensions ( W x D x H ):
* 6.1x2.8x1.7 in (155x70x42 mm)
